cod.238095000, before: green version
Approval:
E13 67R010233
E13 110R000057
PAY ATTENTION!
The pressure sensor at OPEL system (Landi Renzo) uses a different pressure sensor (3,5 bar or 5.5 bar).
Check which type of pressure sensor is used on your car.
Available sensors:
BOSCH 0261230373 3,5bar (earlier 0281002456)
Continental T-MAPC96 3,5bar
Continental T-MAPC97 5,5bar
ELTEK cod.100848 3,5bar ABS
Otherwise order the separate injectors.
Technical data:
Length - 170 mm
Width - 80 mm
Height - 45 mm
Supply voltage - (6-14 Volt)
Operating Temperature - (-40 to 120 ° C)
Response Time: 1.7 ms ± 0.2 ms
Maximum working pressure: 3 bar
Download
4x injector 09SQ99020061
cod.238154000, before: white version
Coil resistance - 1.9 Ω
Without nozzles.
- Coil resistance - 1.9 Ω . SM - aluminum body
cod.23809000
The injector VALTEK 32 after rebranding known injectors OMVL SL.
Technical data suitable for OMVL SL.
Resistance of the coil - 1,7 Ω, 40-60 HP/ 1cyl.
cod.238000131
Coil resistance - 1.9 Ω , Max Flow Rate - 130nl/min-1.2bar
BRC 4cyl. original
