cod.238154000, before: white version
PAY ATTENTION!
The pressure sensor at OPEL system (Landi Renzo) uses a different pressure sensor (3,5 bar or 5.5 bar).
Check which type of pressure sensor is used on your car.
Available sensors:
BOSCH 0261230373 3,5bar (earlier 0281002456)
Continental T-MAPC96 3,5bar
Continental T-MAPC97 5,5bar
ELTEK cod.100848 3,5bar ABS
Otherwise order the separate injectors.
Approval:
E13 67R010233
E13 110R000057
Technical data:
Length - 170 mm
Width - 80 mm
Height - 45 mm
Supply voltage - (6-14 Volt)
Operating Temperature - (-40 to 120 ° C)
Response Time: 1.7 ms ± 0.2 ms
Maximum working pressure: 3 bar
Download
cod.23809000
Coil resistance - 1.9 Ω
Coil resistance - 1.9 Ω, Flow rate - 65-115 L/min
Resistance 1.9 Ohm
The injector VALTEK 32 after rebranding known injectors OMVL SL.
Technical data suitable for OMVL SL.
Valtek 3ohm injection rail for 4cyl.
BRC 4cyl. original
Injection rail HERCULES I-1000 for 4cylinders
Resistance 1.9 Ohm. Max. gas flow: 115 l / min
Injection rail HERCULES BLUE for 4cylinders
Coil resistance - 1.9 Ω , Max Flow Rate - 115Nl/min-1.2bar
Coil resistance - 1.3 Ω
