15-48kW / cylinder
Approval:
E20 67R-017064
110R-007065
Working pressure - 0,95-1,2 bar
Maximum operating pressure - 4.5 bar
Temperature - 20 ° C to 120 ° C
Injector opening time (at a pressure of 1.2 bar) - 2,3 ms
Closing time injectors (at a pressure of 1.2 bar) - 1,3 ms
Capacity range - 15-48kW / cylinder (adjustable nozzle)
Weight - 0.41 kg
Resistance - 1.9 Ohm
Max. flow (at a pressure of 1.2 bar) - 150l/min
Width - 145 mm
Height - 53 mm
The height of the nozzle - 60 mm
2 years warranty
Coil resistance - 1.9 Ω, Flow rate - 65-115 L/min
Valtek 3ohm injection rail 2cyl.
Resistance 1.9 Ohm. Max. gas flow: 115 l / min
Resistance 1.9 Ohm. Max. gas flow: 120 l / min
cod.238096000 , before: black version
237112000 LOVATO.
Max Flow Rate - 130nl/min-1.2bar
Original Vercesi 4.0 with a blue cap. Compatible with Bosch 12185025 plug.
Coil resistance - 2.0 Ω, Maximum flow value - 120Nl / min
Injection rail Hercules Blue 3 cyl
cod. LIS.Y130
Resistance of the coil - 1,7 Ω, 40-60 HP/ 1cyl.
Without nozzles.
