Max Flow Rate - 130nl/min-1.2bar
Approval:
(E8)67R016407
(E8)110R006408
- Max Flow Rate - 130nl/min-1.2bar
- Coil resistance - 1.9 Ω
- Operating temperature - 20 ° C to +120 ° C
- Opening time - 1.9 ms
- Closing Time - 1.2 ms
- Maximum supply pressure - 4.5 bar
- Lifetime - more than 500 million cycles
- The gas inlet nozzle diameter - 6mm
- Diameter of the nozzle exit: gas - 6 mm
- Gas nozzle - 1.5mm (possibly in exchange calibration)
Data sheet
62-70HP/cyl. (16,32)
Original distributor for the AC W031 injection rail with an output for mapsensor or a plug.
33-50 HP / cyl. [ with the possibility of use of the nozzle. ] - Coil resistance - 1.9 Ω
237112000 LOVATO.
4x injector 09SQ99020061
cod. 238000050
Original Vercesi 5.0 with a orange cap. Compatible with Bosch 12185025 plug.
40-60 HP / cyl.
Original Vercesi 4.0 first generation injector with a black cap. Compatible with Bosch 12185025 plug.
Poliauto Mistral JET 21
Original Vercesi 4.0 with a green cap. Compatible with Bosch 12185025 plug.
